Description
SC-5MP-DG 5MP CCTV Dome White Camera features high sensitive colour interline transfer sensor, automatic white balance function and manual pan/tilt mechanism.
Applications
Specifications
Signal System: PAL/NTSC
Image Sensor: SONY/CMOS Sensor
Video Output: 4-in1 (TVI/CVI/AHD and CVBS) or AHD
Sync System: Internal
S/N Ratio: More than 46dB (AGC Off)
Horizontal Resolution: 720P / 960P / 1080P / 3/4/5MP / 8/12MP
Mega Pixel: 1MP / 1.3MP / 2MP / 3/4/5/MP /8/12MP
Lens: 3.6/6/8/2.8-12mm optional
Mini-illumination: 0Lux(IR ON)
E-Shutter: PA::1/50~1/100,1000sec;NTSC:1/60~1/100,000sec
White balance: Auto White Balance
Operation Temperature: ~20C ~50C
Storage Temperature: ~20C ~60C
Power Supply: 12V DC
Power Consumption: About 0.5W
Product Info
MPN/SKU: SC-5MP-DG
Weight: 0.5kg approx
SC-5MP-DG Datasheet - Click Here
